Designed to achieve standardization based on each thread size Reduce the amount of tooling required to cover the valve range UNF based cartridges are made to fit the ISO recommendations for standard cavities Drawings for standard tools are available upon request Special tools can be supplied, consult factory for cost and leadtime
| Flanges | ISO 3019/2 |
|---|---|
| Connection | SAE 3000 – BSPP |
| Shaft Speed | 500-3600 rpm |
| Rated Flow | up to 1220 L/min |
| Outlet Pressure | up to 80 bar |
| Inlet pressure | -0.7 to 3 bar |
